- Size: 29
- Place of Origin: China
- Brand Name: METO
- Model Number: MT-7BBL
- Weight: 1900.000 kg
7BBL complete micro brewing stainless steel machine with 10 barrel hot water systems
Company Information
Factory sale directly with more lower price ,and short delivery time ,also we will offer the free service of teach how to brew beer .
Product Description
Detail information of 7bbl configuration for your reference :
7 BBL Beer Brewing Equipment | |||
Brewing System | Components | Capacity | Specification |
Grinding System | Miller | 300KG/H | Double Roller,Noise<40db |
Heating System | Boiler | 50KG/H | Electric,Gas,Oil,Coal Type/CE certification |
Brewhouse System | Mash/Lauter tun | 7 BBL | Mashing Process:Decoction.Infusion.Multi-step infusion Heating source:Steam,Electric,Gas SUS304/Red copper |
Brew Kettle/ Whirlpool Tank | 7 BBL | ||
Hot Water Tank | 10 BBL | ||
Heat exchanger | 7SQM | Stainless steel plate | |
Fermentation System | Fermentation Tank | 7 Barrel / 14 Barrel | Top manway/Side manway Drying hop port to brew IPA Dimple Plate Cooling jacket Carbonation port to fill CO2 |
Yeast Adding Tank | 7L or 14L | SUS304 Stainless Steel | |
Cooling System | Glycol Water tank | 15 BBL | Equiped with PU level indicator |
Chiller | 5HP | UL/CE certified electric elements,Copeland compressor | |
Pump | 3T | ||
Cleaning System | Disinfection Tank | 100L | SUS304 full welded |
Alkali Tank | 100L | ||
Pump | 3T | ||
Control System | Control Cabinet | Manual/PLC/ HMI | Manual/Semi-automatic/Automatic |
Optional | Auger System | ||
Grain Case | |||
Grist Hydrator | |||
Piping flow panel for Brewhouse | |||
Brewhouse Separate PLC Controller | |||
Customized | |||
Technical Parameter | Power: Voltage:Cusomized Floor space: |
Information of main system of 7bbl brewing equipment .
System I : Brewhosue system
Construction : 2, combinated 3 vessles
Material : SUS304 Stainless Steel , Red copper
Heating : electric , steam (We recommend the steam firstly)
System II: Fermenter System
Construction : top manway
Material : SUS304 Stainless Steel , Red copper
With Dimple Plate
System III: Cooling System
Construction : GWT Chiller Water Pump
Material : SUS304 Stainless Steel
