A. Brewery equipment Description
300L beer brewery equipment , -----Meto - built-in solid objects are proven manufacturing equipment, enabling production of all the world’s known beers by infusion or decoction method. Easy become a popular center of your restaurant,pub and brewery factory.
Our brewery optimalizer helps you to search an optimal configuration of your brewery.several combination of brewhouse to brew different beer
B. Main Features
1. Customize equipment to meet different brewing technology.
2. Famous brand with UL certification,ABB motor, Allen-Bradley and SiemensPLC, Schneider electric element
and so on.
3. Welcome to visit our factory to inspect the equipment,all the cost will be deducted from the first order.
4. Full refund if you did not satisfied with our equipment.
5. Quality and customer experience is our culture.
6. Updating equipment according to our client feedback.
- Place of Origin: China
- Brand Name: METO
- Model Number: MT-500
SPECIFICATIONS FOR 200L BREWERY EQUIPMENT | |||
Brewing System | Components | Capacity | Specification |
Grinding System | Miller | 200KG/H | Double Roller,Noise<30db |
Heating System | Boiler | 30KG/H | Electric,Gas,Oil,Coal Type/CE certification |
Brewhouse System | Mash/Lauter tun | 300L | Mashing Process: Decoction.Infusion.Multi-step infusion Heating source: Steam,Electric,Gas SUS304/Red copper |
Brew Kettle/ Whirlpool Tank | 300L | ||
Hot Water Tank | 500L | ||
Heat exchanger | 3㎡ | Stainless steel plate | |
Fermentation System | Fermentation Tank | 300L/600L | Topmanway/Sidemanway |
Yeast Adding Tank | 3L | SUS304 Stainless Steel | |
Cooling System | Glycol Water tank | 1000L | Equiped with PU level indicator |
Chiiler | 3HP | UL/CE certified electric elements,Copeland compressor | |
Pump | 3T | ||
Cleaning System | Disinfection Tank | 50L | SUS304 full welded |
Alkali Tank | 50L | ||
Pump | 3T | ||
Control System | Control Cabinet | Manual/PLC/HMI | Manual/Semi-automatic/Automatic |
Optional | Auger System | ||
Grain Case | |||
Grist Hydrator | |||
Piping flow panel for Brewhouse | |||
Brewhouse Separate PLC Controller | |||
Customized | |||
Output/Brew | 200L | 300L | 500L | 600L | 800L | 1000L |
Brew/Week | 2-6 | 2-6 | 2-6 | 2-6 | 2-6 | 2-6 |
Output/Week | 400-1200L | 600-1800L | 1000~3000L | 1200~3600L | 1600~4800L | 2000~6000L |
Electric Supply | 3phase/380(220, 415,440…)v/50 (60)Hz | |||||
Heating Source | Electric/Steam | |||||
Area Request | >25M2 | >30M2 | >45M2 | >50M2 | >60M2 | >70M2 |
Brew master | 1 | 1 | 1 | 1 | 1 | 1 |
