- Place of Origin: China
- Brand Name: METO
- Model Number: MT-200
System I : Brewhosue system
Construction : 2 or ombinated 3 vessles
Material : SUS304 Stainless Steel , Red copper
Heating : electric , steam
System II: Fermenter System
Construction : top manway
Material : SUS304 Stainless Steel , Red copper
With Dimple Plate
System III: Cooling System
Construction : GWT Chiller Water Pump
Material : SUS304 Stainless Steel
Welcome to contact with us. Any questions will get a timely response .
Meto Beer Euqipment : Supplying the most microbrewery equipment is our lifelong promise
More details information of self beer brewery equipment , welcome to contact at anytime!
Get intouch
Call us Monday to Sunday at any time .
Tel : 0086 18616768596
- Place of Origin: China
- Brand Name: METO
- Model Number: MT-200
| 200L Small Microbrewery Equipment | |||
| Brewing System | Components | Capacity | Specification |
| Grinding System | Miller | 100KG/H | Double Roller,Noise<40db |
| Heating System | Boiler | 26KG/H | Electric,Gas,Oil,Coal Type/CE certification |
| Brewhouse System | Mash/Lauter tun | 200L | Mashing Process:Decoction.Infusion.Multi-step infusion Heating source:Steam,Electric,Gas SUS304/Red copper |
| Brew Kettle/ Whirlpool Tank | 200L | ||
| Hot Water Tank | 300L | ||
| Heat exchanger | 2SQM | Stainless steel plate | |
| Fermentation System | Fermentation Tank | 200L/400L | Top manway/Side manway Drying hop port to brew IPA Dimple Plate Cooling jacket Carbonation port to fill CO2 |
| Yeast Adding Tank | 2L/4L | SUS304 Stainless Steel | |
| Cooling System | Glycol Water tank | 500L | Equiped with PU level indicator |
| Chiller | 3HP | UL/CE certified electric elements,Copeland compressor | |
| Pump | 3T | ||
| Cleaning System | Disinfection Tank | 50L | SUS304 full welded |
| Alkali Tank | 50L | ||
| Pump | 3T | ||
| Control System | Control Cabinet | Manual/PLC/ HMI | Manual/Semi-automatic/Automatic |
| Optional | Auger System | ||
| Grain Case | |||
| Grist Hydrator | |||
| Piping flow panel for Brewhouse | |||
| Brewhouse Separate PLC Controller | |||
| Customized | |||
| Technical Parameter | Power: Voltage:Cusomized Floor space: | ||
